Hitachi SJ300 Series Quick Reference Guide

28
“C” Group: Intelligent Terminal Functions
Func.
Code
Name / Description
Default
Value
–FE/FU/FR
Set
Value
C001 Terminal [1] function 44 option codes
available
(see page 35)
18
C002 Terminal [2] function 16
C003 Terminal [3] function 06
C004 Terminal [4] function 11
C005 Terminal [5] function 09
C006 Terminal [6] function 03 / 13 / 03
C007 Terminal [7] function 02
C008 Terminal [8] function 01
C011 Terminal [1] active state • 00 Normally open
[NO]
• 01 Normally
closed [NC]
00
C012 Terminal [2] active state 00
C013 Terminal [3] active state 00
C014 Terminal [4] active state 00
C015 Terminal [5] active state 00
C016 Terminal [6] active state 00 / 01 / 00
C017 Terminal [7] active state 00
C018 Terminal [8] active state 00
C019 Terminal [FW] active
state
00
C021 Terminal [11] function 22 option codes
available
(see page 36)
01
C022 Terminal [12] function 00
C023 Terminal [13] function 03
C024 Terminal [14] function 07
C025 Terminal [15] function 08
C026 Alarm relay terminal
function
05
C027 [FM] signal selection 8 option codes
available
(see page 38)
00
C028 [AM] signal selection 00
C029 [AMI] signal selection 00
