Vesa Wall Mount Measurements
Hole Paern
Sizes (mm)
W H
600 400
Screw Sizes
Length (X)
min. (mm) 15
max. (mm) 15
Thread (Y) M8
Installation On An Indented Wall
Side view
E
A
B
C
Plane view
D D
A
B
C
D
E
the product and wall for ventilation and ensure that the ambient temperature is kept between
Do not expose the product to direct sunlight.
We will take no responsibility for any damages or failures in case our products are not being used subject to
these recommendations and/or instructions for use.
