Hitachi UX User Manual

●Specifications 13-1
13. SPECIFICATIONS
Item
Model
UX-E160 W/S UX-D160 W/S UX-B160 W/S
Nozzle size 65μm
Max. print line number Up to 6 lines Up to 3 lines
Maximum number of print
characters
Up to 1,000 characters
Up to 240 characters
(OP: Up to 1000
characters)
Up to 240 characters
Font
4x5 V -
5x5 V V
5x7(8),9x7(8) V V
7x10 V V
11x11 V (Chinese only) V (Chinese only)
10x12 V V
12x16 V V
18x24 V V
24x32 V -
30x40 V -
36x48 V -
Character height 2-10 mm / 0.08-0.39 inches
Display & input device
WYSIWYG design; Display: TFT LCD (10.4" color), backlight provided;
Input device: Touch panel, input sound provided
Maximum print rate
(character per second)
(Font 5x5, space 1, 1line)
Up to 2,296
Up to 1,148
(OP: Up to 2,296)
Up to 1,148
Standard characters Alphanumeric (A-Z, a-z, 0-9), symbols (27), space : Total 90
User pattern
Each dot matrix 200 patterns
(30 × 40, 36 × 48: 50 characters)
Each dot matrix 50 patterns
Print functions Calendar, Count, Font mixture, Passwords security, etc.
Barcode printing
code39, ITF, NW-7, EAN-13, EAN-8, UPC-A,
UPC-E, code128/EAN-128, GS1 DataBar
-
2D code printing Data Matrix , QR code, Micro QR -
Message storage capacity
2,000 messages
(depends on data
content)
300 messages
(Op: Up to 2000
messages
(depends on data
content))
150 messages
Input signal
Print target detection, Rotary encoder pulse,
OP:Printing stop, Reciprocative printing,
Remote control (Run, Stop, High-voltage ON/
OFF, Reset)
(NPN/PNP Selectable)
Print target detection, Rotary encoder pulse
(NPN/PNP Selectable),
OP:Printing stop,
Reciprocative printing,
Remote control (NPN/PNP Selectable)
Output signal
Print ready, Fault, Warning (NPN Only),
OP:Print in progress or Print complete,
Online (NPN/PNP Selectable)
Print ready, Fault, Warning (NPN Only),
OP:Print in progress or Print complete,
Online (NPN/PNP Selectable)
Data interface RS-232C
RS-232C at baud rates selectable up to
115,200bps
Option
(RS-232C at baud rates selectable up to
115,200bps)
Ethernet IEEE802.3, 100BASE-T -
External memory USB for user data storage
Head cable length, angle 4m / 13.1ft, inline / 90 degrees
Operating temperature range 0-50ºC / 32-122ºF (Refer to “Handling guidance of each ink” manual)
Humidity range 30-90% R.H. (No condensation)
Power supply
(Automatic voltage selection)
AC100-120/220-240V±10% 50/60Hz 120VA (AC Inlet)
Corrosive gas There must be no corrosive gas
Overall size
(Width x Depth x Height)
400x320x527mm / 15.7x12.6x20.8 inches
Approximate weight 27kg / 60lbs
