Hitachi UX User Manual

14-1 ●Outside Dimensions
Fig.14-1 Model UX IJ printer outside dimensions
30
201 68
34
128
(With topcover open)
230 400
USB cover
RFID reader
527
747
220
State indicator light
Touch screen
250
(Maintenance
area)
Operating status indicator lamps Knob
Maintenance cover
295
(With maintenance
cover open)
Cabinet mounting screws (M4-2places)
320
Print head cable (4m)
Print head
Power cable (AC100V only)
Power inlet (φ7
〜
10)
Power switch
53
45
9634
18
Exhaust dact (φ50)
31
24
300 300
300
750
Maintenance area
External interface inlets
State indicator light attacting portion
Top cover
Purging air inlet (Rc1/8)
300 340
(Front)
(400)
(320)
68 201
Location of feet
14. SCHEMATIC DIAGRAMS
14.1 Outside Dimensions
