ENGLISH
MODEL RAS-8WHNPE RAS-10WHNPE
Air heat exchanger
Type Multi-pass cross-nned tube
Pipe material Copper
Outer diameter mm 7
Rows 3
Number of tubes in the heat exchanger 198
Fin material Aluminium
Fin pitch 1.4
Maximum Heat exchanger pressure MPa 4.15
Total front area m
2
1.35
Number of evaporators per unit 1
Fan
Fan type Direct drive propeller fan
Fans per unit 2
Outer diameter mm 544
Revolutions rpm 586/717 644/787
Nominal air ow m
3
/min 127 134
Motor
Shell Drip-proof type enclosure
Starting Direct current control
Power W 138 + 138
Quantity 2
Insulation class E
Compressor
Model DA50PHD-D1SE2 DA65PHD-D1SE2
Oil type FVC68D
Quantity 1.90
GENERAL DATA
PMML0335A rev.1 - 04/2016
51
