08-2
8.2 Tanks
Rolling waste water tank
The rollable waste water tank
m
can be pushed
beneath the vehicle when the camper is stati-
onary. It collects the waste water and holds 22
litres. The waste water tank can be transported
on wheels and has an extendable transport
handle
l
, allowing you to transport it to the
appropriate waste disposal place for emptying.
4
5
Built-in fresh water tank
The tank
j
has a model-specic volume of 25
or 50 litres.
The tank is lled with fresh water by means of
the ller neck
k
on the side wall.
The fresh water ller neck is identied by a blue
screw cap as well as a water faucet symbol on
the lower edge of the frame. The screw cap is
opened and closed by means of the enclosed
key for exterior ap locks and the door of the
structure.
Should the tank overow, the excess water is
drained off underneath the vehicle by means of
an overow.
The water can be emptied from the tank by un-
screwing the overow pipe
l
.
1
3
2
3
• Protect the pump from freezing.
• Hard blows or hits as well as very dirty water
can destroy the pump.
• The pump can transmit at most 8.5 l/min.
