03-5
3.4 Front landing wheel
Rotating it upwards and securing it
• Hitch the camper to the base vehicle, aligning
the front landing wheel
j
to the rear end of
the camper.
• Loosen the tommy screw
k
.
• Pull the spindle tube
l
up as far as possible.
• Tighten the tommy screw
k
.
• Turn the crank of the front landing wheel
m
clockwise to raise the wheel as far as possible
and secure it to prevent it from twisting.
Before driving, always make sure
that the front landing wheel has been
rotated upwards as far as possible
and secure it.
To lower
• Loosen the tommy screw
k
.
• Lower the spindle tube
l
as far as possible
until the front landing wheel is approx. 70 mm
above the ground.
• Tighten the tommy screw
k
.
• Turn the crank of the front landing wheel
m
counter-clockwise to lower the wheel until it
touches the ground.
• Unhitch the camper from the base vehicle
and, if necessary, lower the front land wheel
further.
1
2
3
4
4
3
2
