06-11
Roof fan
The roof fan can be set up either on one or both
sides.
To open
• Press the spring lock towards the inside of
the roof fan while, at the same time, using the
handle to press the roof fan upwards.
To close
• Use both handles to pull the roof fan rmly
downwards until both spring locks have lat-
ched into place.
Shade/insect screen
When the insect screen is shut and locked to-
gether with the shade, it is still possible to pull
down the shade. When you pull down the shade,
the insect screen will automatically be pulled
with it.
To close
• Press the lock towards the outside of the roof
fan.
• Pull the handle of the screen towards the
handle of the opposite screen and let it latch
into place.
To open
• Press the handle together; this releases the
lock.
• Take hold of the handle and slowly guide the
screen back.
