06-6
The swivelling table is not fastened
to the oor. Before driving, lower the
table and secure the rollers by means
of the attached transportation locks.
Swivelling table
To lower
• Push the handle
o
upwards.
• Swivel the table top downwards in an arc until
the handle locks into place.
To turn
• There are rollers on the table legs, shifted 45°,
which enable the table to be turned around its
centre point in any desired direction.
3
4
5
Hanging table
To lower
•
Raise the front end of the table top by approx. 30°.
• Pull down the lower part of the table leg
l
,
fold it over by 90° and lay it alongside.
• Fold out the supporting legs
m
by 90°.
•
Pull the table top out of the upper wall brackets
n
.
• Raise the front end of the table top by approx.
30° and hook it into the lower wall brackets.
• Place the supporting legs at the front edge of
the table top on the oor.
6
