Honda CRF230F 2007 User Manual

(1)
LEFT SIDE
(1) side stand spring
104
Side Stand
Servicing Your Honda
Saf ety PrecautionsRefer to on page . Check the side stand spring ( ) for damage
and loss of tension.
Check the side stand assembly for freedom
of movement.
If the side stand is stiff or squeaky, clean the
pivot area and lubricate the pivot bolt with
clean engine oil.
1.
2.
143
06/03/17 17:33:27 31KPS640_113

Honda CRF230F 2007 Specifications

General

Engine Type	223cc air-cooled single-cylinder four-stroke
Bore and Stroke	65.5mm x 66.2mm
Compression Ratio	9.0:1
Ignition	CDI
Front Brake	Single 240mm disc
Rear Brake	Drum
Front Tire	80/100-21
Rear Tire	100/100-18
Seat Height	34.1 inches
Ground Clearance	11.7 inches
Curb Weight	249 pounds
Fuel System	Carburetor
Final Drive	Chain
Front Suspension	37mm leading-axle Showa fork
Rear Suspension	Pro-Link Showa single shock
Transmission	6-speed
