āˆ’āˆ’1/16 1/4 in (2 6 mm)
(1) rubber dust cover
(2) upper lock nut
(3) upper adjuster
(1) freeplay
(1)
(3)
(2)
RIGHT SIDE
RIGHT SIDE
(1)
72
Throttle Freeplay
Throttle
Servicing Your Honda
Saf ety PrecautionsRefer to on page .
Minor adjustments are generally made with the
upper adjuster.
Upper Adjustment
Check freeplay ( ).
Freeplay:
Inspection
If necessary, adjust to the specified range.
Pull the rubber dust cover ( ) back.
Loosen the upper lock nut ( ) on the throttle
cable mechanism.
Turn the upper adjuster ( ).
1.
2.
3.
1
1
2
3
43
