18
Operating Controls
Operating Controls
Engine Stop Button
Start Button Front Brake Lever
Throttle
Starting Procedure,
The start button is used for starting the engine.
Pushing the button in starts the engine. See
page .
When the start button is pushed, the starter
motor will crank the engine.
The engine stop button is used to turn the
engine off during normal riding situations. To
operate, push the button in and hold it in until
the engine stops completely.
The front brake lever is used to slow or stop
your motorcycle. To operate, pull the lever. For
information on braking techniques, see
page .
The throttle controls engine rpm (speed). To
increase engine rpm, rotate the grip toward you.
To reduce engine rpm, rotate the grip away
from you. The throttle will automatically return
to the closed position (engine idle) when you
remove your hand.
29
35
06/03/17 17:20:23 31KPS640_027

Honda CRF230F 2007 Specifications

General

Engine Type	223cc air-cooled single-cylinder four-stroke
Bore and Stroke	65.5mm x 66.2mm
Compression Ratio	9.0:1
Ignition	CDI
Front Brake	Single 240mm disc
Rear Brake	Drum
Front Tire	80/100-21
Rear Tire	100/100-18
Seat Height	34.1 inches
Ground Clearance	11.7 inches
Curb Weight	249 pounds
Fuel System	Carburetor
Final Drive	Chain
Front Suspension	37mm leading-axle Showa fork
Rear Suspension	Pro-Link Showa single shock
Transmission	6-speed
