Honda CRF230F 2007 User Manual

19
Operating Controls
Operating Controls
Clutch Lever
Shift Lever
Rear Brake Pedal
Side Stand
Shif ting Gears,
The clutch lever is used to disengage the clutch
whenever you shift gears. To operate, pull the
clutch lever in all the way before shifting, then
slowly release it after shifting.
The shift lever is used to select the next higher
or lower gear in the transmission. To operate,
raise the shift lever (after pulling in the clutch
lever) to engage the next higher gear or depress
the shift lever to engage the next lower gear.
See page .
The rear brake pedal is used to slow or stop
your motorcycle. To operate, depress the pedal.
For information on braking techniques, see
page .
The side stand is used to support your
motorcycle while parked (page ). To operate,
use your foot to lower the stand. Before riding,
raise the stand.
33
35
37
06/03/17 17:20:32 31KPS640_028

Honda CRF230F 2007 Specifications

General

Engine Type	223cc air-cooled single-cylinder four-stroke
Bore and Stroke	65.5mm x 66.2mm
Compression Ratio	9.0:1
Ignition	CDI
Front Brake	Single 240mm disc
Rear Brake	Drum
Front Tire	80/100-21
Rear Tire	100/100-18
Seat Height	34.1 inches
Ground Clearance	11.7 inches
Curb Weight	249 pounds
Fuel System	Carburetor
Final Drive	Chain
Front Suspension	37mm leading-axle Showa fork
Rear Suspension	Pro-Link Showa single shock
Transmission	6-speed
