ASSEMBLY
14
ASSEMBLY
Unpacking
1. Remove the generator and loose parts box from the carton.
2. Compare the loose parts with the inventory list below.
Tools Required: 12 mm wrench, 10 mm wrench or Phillips head screwdriver for
battery connections, pliers (not included)
Do not add fuel or oil before tipping the generator. Oil or fuel may damage the
engine or your property.
Loose Parts
Check all loose parts against the following list.
Ref. No. Description Qty.
1 Wheel 2
2Axle 1
3Stand 2
4 20 mm Washer 2
5 4.0×28 mm
Cotter pin
2
6 8×20 mm
Flange bolt
8
31Z376200.book 14 ページ ２０２０年２月１４日 金曜日 午前１０時３９分
