ASSEMBLY
15
Wheel Kit Installation
Do not operate the generator without the wheel kit installed. The wheel kit
provides air space between the ground and the generator air intake.
Generators with standard equipment transport wheels must be operated with the
wheels and stands installed to provide air space between the ground and the
generator air intake. This prevents fuel, dirt, or debris from being drawn into the
generator air intake, which can cause generator or engine damage.
1. Install the two stands on the under frame by tightening four 8×20 mm flange
bolts.
2. Install the two wheels on the axle by tightening the 20 mm washers and
4.0×28 mm cotter pins. After installing the split pins, bend the pins to ensure
that the wheels are secured to the axle.
Operating the generator without the
wheel kit installed can pinch or block air
vent tubes or fuel drain tubes, causing
fuel to spill on the ground or, inside or
around the generator.
Spilled fuel can cause a fire and you can
be burned or seriously injured.
Always operate the generator with the
wheel kit installed and do not modify
any part of the generator, including air,
drain and fuel tubes, or covers, panels
and air intakes.
