SERVICE INFORMATION
LUBRICATION & SEAL POINTS
Material Location Remarks
Engine oil Crankshaft pin and gear teeth
Piston outer surface, ring groove and piston pin hole
Piston pin outer surface
Piston ring entire surface
Cylinder inner surface
Connecting rod big and small end bearing
Connecting rod bolt threads and seating surface
Camshaft cam profile and journal
Valve lifter pivot, pivot end and slipper surface
Valve stem sliding surface and stem end
Valve rocker arm tappet surface and pivot
Rocker arm pivot threads and pivot
Flywheel nut threads and seating surface
Governor weight holder gear and sliding surface
Governor holder shaft journal
Governor arm shaft journal
Cylinder head bolt threads and seating surface
P.T.O. shaft gear teeth and journal Reduction unit (gear type)
Drive sprocket, P.T.O. shaft gear teeth and journal Reduction unit (chain type:
without clutch)
Drive sprocket, P.T.O. shaft, clutch center gear teeth
and journal
Reduction unit (chain type:
with clutch)
Clutch disc, clutch plate entire surface
Multi-purpose grease Oil seal lips
Control lever sliding surface
Recoil starter case pulley sliding surface
Recoil starter ratchet sliding surface
Recoil starter spring retainer inside
Use molybdenum oil solution
(mixture of the engine oil and
molybdenum grease in a ratio
of 1:1)
Camshaft cam profile When installing a new
camshaft
Threebond® 2430 or
equivalent
Recoil starter center screw threads
LOCTITE® 638 or equivalent Limiter cap inside
