9
4. CONTROLS
DESCRIPTION OF CONTROLS
Fuel Valve
The fuel valve opens and closes the fuel passage from the fuel tank to the
carburettor. The fuel valve must be ON to start and operate the mower. The
fuel valve should be kept OFF when the mower is not in use.
NOTE: Fuel Valve may vary in appearance depending on engine model.
Throttle Lever
.
CHOKE For starting a cold engine ( Not for HRU19K1 or HRU19M1 )
HIGH For restarting a warm engine and for mowing
LOW For idling the engine

Questions and Answers:

Honda HRU196M1 Specifications

General IconGeneral
Cutting Width19 inches
Deck MaterialSteel
Starter TypeRecoil
Engine Type4-stroke
Cutting Height AdjustmentLever
Wheel Size8 inches
Engine Power3.6 kW (4.8 hp)
