63
11. SET-UP INSTRUCTIONS
UNPACKING
Remove all protective packaging materials from the mower.
Handlebar Setup
1. Loosen the Grip Handle Joints on the handlebar, taking care not to lose the
washers, and raise the handlebar into the normal position. Tighten the grip
handle joints securely.
2. Check that the rope guide is installed correctly and that the locking nut is
tight.
3. Ensure all cable ties are fitted correctly and that operating cables are
correctly routed and not binding ( Refer Page 64).
4. On Models fitted with a Snorkel, check that the air cleaner hose is firmly
connected to the air cleaner cover and throttle lever cover.
To Next Page
