10
4. CONTROLS continued
Blade Control Lever ( HRU196M1 and all 21” Models )
This lever is connected to the Roto-Stop blade control system. The blades will
not turn unless the blade control button is pushed in conjunction with the
blade control lever being pushed forward.
NOTE: Engine will Stop in this
position on models fitted
with Fly Wheel Brake

Questions and Answers:

Honda HRU196M1 Specifications

General IconGeneral
Cutting Width19 inches
Deck MaterialSteel
Starter TypeRecoil
Engine Type4-stroke
Cutting Height AdjustmentLever
Wheel Size8 inches
Engine Power3.6 kW (4.8 hp)
