LIGHTS/METERS/SWITCHES
TURN SIGNAL/TAIL LIGHT BULB
TURN SIGNAL LIGHT BULB REPLACEMENT
Remove the turn signal lens attaching screw.
While pushing in, turn the bulb counterclockwise to remove.
Replace the bulb, if necessary.
Install in the reverse order of removal.
NOTE
• Seat the rubber gasket properly.
(1) SCREW (2) BULB
TAIL LIGHT/LICENSE LIGHT BULB REPLACEMENT
Remove the tail light lens attaching screws and lens.
While pushing in, turn the bulb counterclockwise to remove.
Replace the bulb, if necessary.
Install in the reverse order of removal.
NOTE
• Seat the rubber gasket properly.
Remove the license light cover mounting nuts and cover.
Remove the lens and bulb.
While pushing in, turn the bulb counterclockwise to remove.
Replace the bulb, if necessary.
Install the bulb and lens in the reverse order of removal.
NEUTRAL SWITCH
Remove the drive sprocket cover (page 8-2).
Check the neutral switch for continuity between the switch
terminal and ground.
There should be continuity when the transmission is in neutral.
There should be no continuity with the transmission in any
gear.
(1) NEUTRAL SWITCH
19-5
