Honda NX250 1989 User Manual

FAIRING/EXHAUST SYSTEM
REAR CARRIER (AFTER'88)
REMOVAL
Remote the caps from the carrier
Loosen the carrier base 6 mm SH bolts more than five threads.
Remove the socket bolts and nuts.
Remove the rear carrier assembly by pulling upward white
spreading both lower ends.
INSTALLATION
Install the rear carrier in the reverse order of removal.
[1) SOCKET (2) CARRIER
BOLTS
(3) CAP
{51 NUTS
15-3

Honda NX250 1989 Specifications

General

Year	1989
Manufacturer	Honda
Model	NX250
Category	Dual-sport
Displacement	249 cc
Compression Ratio	11.0:1
Ignition	CDI
Transmission	6-speed
Final Drive	Chain
Front Suspension	Telescopic fork
Rear Suspension	Pro-Link single shock
Front Brake	Single disc
Rear Brake	Drum
Front Tire	3.00-21
Seat Height	830 mm
Engine Type	Single cylinder, four-stroke
Bore x Stroke	70.0 x 64.8 mm
Carburetion	Keihin
