Honda Outboard Motor BF130A User Manual

25
Common Controls
Power Trim/Tilt Switch
CONTROLS AND FEATURES
(side-mount type) (top-mount type)
(panel-mount type)
CONTROL
LEVER
CONTROL LEVER
CONTROL
LEVER
DUAL TYPE
(LEFT) (RIGHT)
CCOONNTTRROOLL
LLEEVVEERR
POWER TRIM/TILT SWITCH
POWER
TRIM/TILT
SWITCH
POWER TRIM/TILT SWITCH
POWER TRIM/TILT SWITCH
SINGLE TYPE
The power trim/tilt switch is located
on the control lever. It is a rocker
switch with UP and DN (down)
positions for changing the angle of
the outboard motor.
You can use the power trim/tilt
switch anytime the ignition switch is
ON, whether the boat is underway or
stopped.
Trim the outboard motor to obtain
the best performance and stability (p.
).
Tilt the outboard motor for shallow
water operation, beaching, launching,
or mooring.
51
02/07/23 13:03:57 31ZW5601_026
