30
Oil Pressure Indicator Overheating Indicator
CONTROLS AND FEATURES
(side-mount type) (side-mount type)
(panel-mount/top-mount types) (panel-mount/top-mount types)
(GREEN)
(GREEN)
(RED)
(RED)
When the green light is lit, oil
pressure is OK.
If oil pressure becomes low, the
green light will go off, and the
engine protection system will limit
engine speed.
Remote controls are also equipped
with a buzzer that sounds when the
green light goes off.
Low oil pressure indicates that the
engine oil level is low, or that there is
a problem with the engine lubrication
system.
02/07/23 13:04:52 31ZW5601_031
