78
Propeller Replacement
SERVICING YOUR OUTBOARD MOTOR
PROPELLER
COTTER PIN
THRUST WASHER
CASTLE NUT
PLAIN WASHER
Removal
Installation
Before replacing the propeller,
remove the clip from the engine stop
switch to prevent any possibility of
the engine being started while you
are working with the propeller.
The propeller blades may have sharp
edges, so wear heavy gloves to
protect your hands.
Remove the cotter pin, unscrew
the castle nut, remove the washer,
then remove the propeller and
thrust washer.
Inspect the propeller shaft for any
fishing line or debris.
Apply marine-grade grease to the
propeller shaft and beveled surface
of the thrust washer.
Install the propeller in the reverse
order of removal.
Install the thrust washer with the
grooved side toward the gear case.
Use a genuine Honda cotter pin
and bend the pin ends as shown.
1.
2.
2.
1.
02/07/23 13:13:40 31ZW5601_079
