1/16 3/16 in
(2 4 mm)
1/16 3/16 in (2 4 mm)
(2)
(6)
(4)
LEFT HANDLEBAR
(1)
(5)
(3)
(4) rubber sleeve
(5) lock nut
(6) adjusting nut
(1) dust cover
(2) reverse assist lever
(3) rear brake lever
133
Reverse Lock System Adjustment
Servicing Your Honda
Reverse Lock System
Saf ety Precautions
Other Checks
Check the reverse assist lever and cable for loose connections or other
damage. If the cable is worn or kinked, have it replaced by your Honda
dealer.
Refer to on page .
Return the dust cover and rubber sleeve.
Turn over the dust cover ( ).
Check the reverse assist lever ( ) freeplay, measured at the rear brake
lever ( ) end near the cable:
To adjust, slide the rubber sleeve ( ), loosen the lock nut ( ) and turn
the adjusting nut ( ).
After adjustment, tighten the lock nut securely.
1.
2.
3.
4.
6
1
3
5
89
4
2
０９／０５／１１ １５：０２：０８ ３１ＨＰ４８３０ ０１４２
