3.51 US gal (13.3 )
0.77 US gal (2.9
)
(3) (2)
(1)
(3) red band(1) fuel gauge
(2) gauge needle
23
Fuel Gauge
Indicators & Displays
Instruments & Controls
The fuel gauge ( ) shows the approximate fuel supply available. At F
(Full), the fuel tank capacity including reserve is:
When the gauge needle ( ) enters the red band ( ), fuel will be low and
you should refill the tank as soon as possible. The amount of fuel left in
the tank when the needle enters the red band is approximately:
23
1
