(1) odometer
(2)(1)
(1) tripmeter (2) hourmeter/odometer/tripmeter select button
(1) (2)
(2) hourmeter/odometer/tripmeter select button
21
Odometer
Tripmeter
Indicators & Displays
Instruments & Controls
When selected, the odometer ( ) registers total distance traveled in
miles while the ignition is ON ( ). To change the display from tripmeter
or hourmeter to odometer, press and release the hourmeter/odometer/
tripmeter select button ( ).
When selected, the tripmeter ( ) shows mileage per trip while the
ignition is ON ( ). To change the display from odometer or hourmeter
to tripmeter, press and release the hourmeter/odometer/tripmeter select
button ( ). To reset the tripmeter to zero, press the hourmeter/odometer/
tripmeter select button and hold it in for at least 2 seconds.
1
1
2
2
０９／０５／１１ １４：４４：４７ ３１ＨＰ４８３０ ００３０
