(1)
REAR
(1) bolts
(2) muffler tail cover
(3) spark arrester
(4) gasket
(5) muffler
(2)
(3)
(4)
(5)
125
Spark Arrester
Servicing Your Honda
Saf ety PrecautionsRefer to on page .
The spark arrester must be serviced every 100 operating hours to
maintain its efficiency.
Regular servicing prevents carbon build up (which can diminish engine
performance) and also complies with USDA regulations for regular
maintenance to assure proper function. The spark arrester prevents
random sparks from the combustion process in your engine from
reaching the environment.
Allow the engine and muffler to cool.
(cont’d)
Remove the bolts ( ), the muffler tail cover ( ), the spark arrester
( ), and the gasket ( ) from the muffler ( ).
1.
2. 1 2
34 5
77
07/04/04 11:27:14 31HP1640_134
