1-1
Section 1
Overview
The Emergency Communication System Packages are a combination of the addressable fire alarm
control panel and voice integration control all in one package. The general idea of the Emergency
Communication System is to activate a message giving building occupants instructions about an
emergency event. This manual contains information on how to install and operate the following
Emergency Communication System Packages:
1.1 Optional Accessories
This manual also contains information on how to install the following compatible accessory with the
ECS series equipment:
Model Number Consists of These Part Numbers
ECS-Series
IFP-100ECS
IFP-100 FACP
ECS-VCM (Voice control Module)
IFP-1000ECS
IFP-1000 FACP
ECS-VCM (Voice control Module)
IFP-2000ECS
IFP-2000 FACP
ECS-VCM (Voice control Module)
IFP-300ECS
IFP-300
ECS-NVCM (Network Voice Control Module)
IFP-2100ECS
IFP-2100
ECS-NVCM (Network Voice Control Module)
ECS-LOC
ECS-RVM (Remote Voice Module)
RA-2000 (Remote Annunciator)
ECS-LOC2100
ECS-RVM (Remote Voice Module)
RA-2000 (Remote Annunciator)
Model Number Description Compatible With
ECS-SW24 Adds 24 additional switches to the ECS-VCM, ECS-NVCM
or ECS-RVM to manually select various voice output
groups for emergency announcements from the on-board
microphone.
IFP-100ECS, IFP-1000ECS,
IFP-2000ECS,IFP-300ECS, and IFP-
2100ECS
ECS-50W / ECS-50WB* 50 watt amplifier with 4 separate audio circuits. IFP-100ECS, IFP-1000ECS,
IFP-2000ECS, IFP-300ECS, and IFP-
2100ECS
ECS-125W 125 watt amplifier with 4 separate audio circuits. IFP-100ECS, IFP-1000ECS,
IFP-2000ECS, IFP-300ECS, and IFP-
2100ECS
ECS-CE4 Provides four additional audio circuits for each ECS-50W or
ECS-125W.
ECS-50W or ECS-125W
ECS-VCM Voice Control Module IFP-100ECS, IFP-1000ECS,
IFP-2000ECS
ECS-NVCM Network Voice Control Module IFP-2100ECS, IFP-300ECS
