Honeywell ESSER IQ8Control M User Manual

Fire Alarm Control Panel IQ8Control C / M
114 FB 798951.10.GB0 / 04.15
* Master box, internal (device module)
Analog channel Function
Normal value range FACP
IQ8Control
Ana 1 Monitoring input, master box (K1) 14 ... 185
Ana 2 Not occupied 00
Ana 3 Not occupied 00
Ana 4 Not occupied 00
Ana 5 Not occupied 00
* Ana 2 = “0” with activated master box *
* 3 relay, internal (device module)
Analog channel Function
Normal value range FACP
IQ8Control
Ana 1 Relay 1 (K2) 70 ... 120
Ana 2 Relay 2 (K3) 70 ... 120
Ana 3 Relay 3 (K4) 70 ... 120
Ana 4 Not occupied 00
Ana 5 Not occupied 00
* Ana 1 ... Ana 3 = “0” with inverse or activated relays *0
Primary loop, internal (device module)
Analog
channel
Function
Normal value range FACP
IQ8Control
Ana 1 Monitoring input 70 ... 120
Ana 2 Not occupied 00
Ana 3 Not occupied 00
Ana 4 Not occupied 00
Ana 5 Not occupied 00
