MAX SETTING OPTIONS
Setting with User Cards/Tags/Fobs
Proximity user cards/tags/fobs can be used to set the system. This is done by assigning a user
with one of the setting options. When the card is held against a MAX module or keyprox for
five seconds, the card-held function assigned to the card user is activated. For example, if the
MAX function assigned is 13 = Part Set, then activating the card held function results in the
system being part set. For access control readers, a function button or triple swipe is required
to activate the card function.
If a user is assigned group choice, then a keypad will have to be accessed to select the group
for setting after swiping the card.
Dual Focus
If a # is assigned to a particular users pin and their max card number, then the user will have
dual focus operation. This means that they will have to enter their pin first, before setting with
the max card and vice versa.
Keyprox
A keyprox is a keypad that has a card reader built in. They are normally installed on systems
where dual focus setting and unsetting are used. Keyproxes are used as a keypad and MAX as
detailed above, but the card is held against the lower right corner of the keypad as shown in
the following diagram:
1
2
3
A
4
5
6
B
7
8
9
ent
*
0
#
esc
