Section 3: Programming the Communicator

3-9

4204 Relay Outputs map to communicator zones as follows:

First 4204 Zones

(device address entered in Prompt 14):

Second 4204 Zones

(device address entered in Prompt 14, plus 1):

Relay 1 = Zone 1

Relay 2 = Zone 2

Relay 3 = Zone 3

Relay 4 = Zone 4 or conditional zone trigger if

“report only if armed” is selected in any zone 1-3

when using single 4204 mode.

NOTE: Zone 4 status is not reported when being

used as the conditional (arming) trigger zone.

Relay 1 = Zone 5

Relay 2 = Zone 6

Relay 3 = Zone 7

Relay 4 = Zone 8 or conditional zone trigger if

“report only if armed” is selected in any zone 1-7

when using Two-4204 mode.

NOTE: Zone 8 status is not reported when being

used as the conditional (arming) trigger zone or if

tamper reporting is enabled.

When using the communicator in 4204 Emulation Mode, DO NOT enable the communicator

(or LRR) in control panel programming. Instead, enable the module device address(es) and

program the appropriate relay activation functions for the relay-zones being used. In some

control panels, it is called “relay programming” and in others it is called “output device

programming.” It is recommended that “close and stay closed” (usually choice 2) action is

selected. Selection of momentary activation will cause the communicator to generate an

alarm and NOT a restore, even if the communicator is programmed to send a restore for the

given zone.

In 4204 mode, messages are reported in ADEMCO High-Speed format. Zone alarms

(status 7) are reported with “1” (alarm) or “3” (restore) displayed in the zone position for the

respective zone (e.g. alarm on zone 2: 5155 5555 7; restore 5355 5555 7). A supervision fault

trouble message is automatically sent if the communicator detects no activity on its connec-

tion to the control panel. The message is: 5555 5515 5; restore message is: 5555 5535 5.

Refer to Table 3-4 for 4204 Emulation Mode programming and follow the prompts that

pertain to 4204 or Two-4204 mode. A “X”

indicates whether the prompt applies to that mode.
