GSMX4G / GSMXCN4G Installation and Setup Guide
– 13 –
NOTE: The central station can remotely block access to local
device programming. If this has been done, prompt on the
right appears.
Access to Prog
Mode Denied
The default programming values for each prompt are shown in parentheses
in the PROMPTS column. Further, the “Programming Options” table (next
page) shows all the prompts for this programming mode. Depending on your
answers, unnecessary prompts will be bypassed and you will advance to the
next appropriate prompt.
Programming for 4204 and Two-4204 Emulation Modes
In this mode the communicator emulates a 4204 module (or two) and appears
to the control panel as a 4204 module. If two 4204s are enabled in the
communicator, it acts as two 4204s using consecutive device addresses.
The compatible Honeywell VISTA series or First Alert control panel sends
data (triggers) to the communicator as if it were a 4204 module. (The control
panel must be configured to recognize one or two 4204 relay modules
accordingly.) On VISTA-32FB (or higher) control panels and First Alert
equivalents, addresses 6 and 13 should not be used when the secondary 4204
is enabled. Messages are sent in ADEMCO High-Speed format.
See your control panel Installation and Setup Guide for the number of
4204 modules supported.
4204 Emulation Mode Options
For control panels that do not support ECP communication, the 4204
Emulation modes provide a means of sending up to eight unique reports
based on defined system conditions. In 4204 mode, the communicator func-
tions as a logical 4204 Relay Module, where each relay number, referred to in
the communicator as zone number, can be programmed to send a report
based on the output function programmed in the control panel for that relay.
Each relay-zone can also be programmed to; send a restore message of the
reported condition, delay the transmission of messages, and to send reports
only when a conditional zone is triggered (armed).
In single 4204 mode, the communicator supports up to four relay-zones. In
Two-4204 mode, the communicator functions as two 4204 modules,
supporting up to eight relay-zones. Refer to the following table.
