Performance Series IP Camera Software Configuration Guide
56
Parameter Function
Area
Configure the motion detection region, its sensitivity, and area. The default settings
covers the entire area. Click Save to enable these settings. See Configuring the
Motion Detection Area on page 56.
Record When Record is enabled, you can trigger motion detection to activate recording.
Record Delay
The system can delay recording for a specified time after the alarm has ended.
Choose a delay period from 10s to 300s.
Send Email
When this function is enabled, the system sends an email alert when an alarm
occurs.
Snapshot
Select the check box to enable the system to back up motion detection snapshot
files. (See Path on page 44 for information about configuring where snapshots are
saved.)
Configuring the Working Period
Figure 6-2 Configuring the Working Period
Configuring the Motion Detection Area
Figure 6-3 Configuring the Motion Detection Area
