About the System (cont’d)
7
Control Panel Compatibility
The table below lists compatible control panels and their software revision levels.
NOTE: For SIA installations used with a VISTA-128BPTSIA Control, see the SIA CP-01 Quick
Reference Chart, Document # 800-09699 located at:
http://www.security.honeywell.com/hsc/resources/MyWebTech
* Not evaluated by UL.
NOTE: Tuxedo may only be used in the following UL/cUL installations: UL 365, UL609, UL 985,
UL1023, UL 1610, CAN/ULC-S303, CAN/ULC-S304, ULC-S545, ULC/ORD-C1023, and
ANSI/SIA CP-01-2010.
To obtain the software revision level on commercial panels:
• From program mode, enter #92 on the keypad (this can be done from the Console Mode).
The second line of the keypad displays the software revision level (w/out the decimal point).
To obtain the software revision level on residential panels:
• From the Home Screen press Setup/System setup /Central Station Setup/ enter installer
code/ press the panel configuration icon; the software revision level is displayed.
• The keypad sound suppression feature available in some commercial panels is not
compatible with the Tuxedo keypad.
• The ‘Voice Chime’ feature is a residential control feature only.
NOTE: If using the maximum number of keypads, an additional auxiliary power supply may be needed.
Refer to the “Wiring” and “Specifications” section for more information.
Maximum Number of Keypads
Minimum Software
Revision Level
VISTA-15P, VISTA-20P, FA148CP,
FA168CPS
2 3.0
VISTA-20P, FA168CPS 4 5.0
* VISTA-21IP 4 1.0
VISTA-128BP, VISTA-250BP 3 4.4
VISTA-128BPEN 3 7.0
VISTA-128FBP, VISTA-250FBP,
FA1670C
3 4.1
VISTA-128FBPN 3 5.1
VISTA-128BPT, VISTA-250BPT, VISTA-
128BPTSIA, FA1660CT
6 10.1
FA1660C, FA1700C 3 3.0
