Table 3-1 Computer major component descriptions and part numbers (continued)
Item Component Spare part number
(17) 80 W M57161-001
(18) 60 W M57160-001
Heat sink (includes replacement thermal material)
NOTE: Thermal gel is available as spare part number M57182-001. Thermal grease is available as
spare part number M57183-001.
M54774-001
(19) Models with RTX graphics M62226-001
(20) Models with GTX graphics M62227-001
WLAN module (not illustrated)
NOTE: WLAN module protective shielding is available as spare part number M14330-001.
Intel Wi-Fi 6 AX201-W + Bluetooth 5 (non-vPro) L92724-006
Intel Wi-Fi 6 AX210 + Bluetooth 5.2 (non-vPro) M27269-006
Display assembly subcomponents
To identify the display assembly subcomponents, use this illustration and table.
18 Chapter 3 Illustrated parts catalog
