HP 16-b0 Series User Manual

3. Remove the battery from the computer (3).
To replace the battery, reverse the removal procedures.
Solid-state drive
To remove the solid-state drive, use this procedure and illustration.
Table 5-3 Solid-state drive descriptions and part numbers
Description Spare part number
1 TB, PCIe M16560-001
512 GB, PCIe M17436-001
1 TB + 32 GB Optane memory L85374-001
512 GB + 32 GB Optane memory L85366-001
Before removing the solid-state drive, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 31).
2. Remove the bottom cover (see Bottom cover on page 31).
3. Disconnect the battery cable from the system board (see Battery on page 32).
Remove the solid-state drive:
1. Remove the Phillips M2.0 × 2.5 screw (1) that secures the drive to the computer.
34 Chapter 5 Removal and replacement procedures for authorized service provider parts
