HP 245 G8 User Manual

Table 5-4 Hard drive descriptions and part numbers
Description Spare part number
1 TB, 5400 rpm, 7 mm L30422-005
500 GB, 7200 rpm, 7 mm 703267-005
500 GB, 5400 rpm, 7 mm 778186-005
Hard drive cable L23187-001
Hard drive bracket L24490-001
Before removing the hard drive, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 26).
2. Remove the rubber feet (see Computer feet on page 26).
3. Remove the bottom cover (see Bottom cover on page 27).
4. Remove the battery (see Battery on page 28).
Remove the hard drive:
1. Disconnect the cable (1) from the system board and remove the cable (2).
2. Lift the hard drive (3), and then remove it (4) from the computer.
3. To remove the hard drive bracket, pull the holder sides (1) up and away from the hard drive, and then
remove the bracket cover (2) from the hard drive.
30 Chapter 5 Removal and replacement procedures for authorized service provider parts

HP 245 G8 Specifications

General

Battery	3-cell, 41 Wh Li-ion
Dimensions	32.4 x 22.59 x 1.99 cm
Storage	256 GB PCIe NVMe M.2 SSD
Display	14-inch HD (1366 x 768)
Graphics	AMD Radeon Graphics
Operating System	Windows 10 / Windows 11
Weight	1.47 kg
Ports	1 x RJ-45, 1 x headphone/microphone combo
Wireless	Bluetooth 4.2
Processor	AMD Ryzen 3 5300U, AMD Ryzen 5 3500U
RAM	8 GB DDR4-3200
