Mounting the monitor head
The monitor head can be attached to a wall, swing arm, or other mounting xture.
IMPORTANT: This monitor supports the VESA industry-standard 100 mm mounting holes. To attach a third-
party mounting solution to the monitor, four 4 mm, 0.7 pitch, and 10 mm–long screws are required. Longer
screws may damage the monitor. It is important to verify that the manufacturer’s mounting solution is
compliant with the VESA standard and is rated to support the weight of the monitor head. For best
performance, use the power and video cables provided with the monitor.
NOTE: This apparatus is intended to be supported by UL– or CSA–Listed wall-mount bracket.
Removing the monitor stand
You can remove the monitor head from the stand to install the monitor head on a wall, a swing arm, or other
mounting xture.
IMPORTANT: Before beginning to disassemble the monitor, be sure that the monitor is turned o and all
cables are disconnected.
1. Disconnect and remove all cables from the monitor.
2. Position the monitor head facedown on a at surface covered by a clean, dry cloth.
3. Remove the two screws on the underside of the stand’s hinge (1), and then slide the stand o the
monitor head (2).
10 Chapter 1 Getting started
