Configuring Advanced Threat Protection

Dynamic IP Lockdown

■ The DHCP binding database allows VLANs enabled for DHCP

snooping to be known on ports configured for dynamic IP lockdown.

As new IP-to-MAC address and VLAN bindings are learned, a corre-

sponding permit rule is dynamically created and applied to the port

(preceding the final deny any vlan <VLAN_IDs> rule as shown in the

example in Figure 11-4. These VLAN_IDs correspond to the subset of

configured and enabled VLANS for which DHCP snooping has been

configured.

■ For dynamic IP lockdown to work, a port must be a member of at

least one VLAN that has DHCP snooping enabled.

■ Disabling DHCP snooping on a VLAN causes Dynamic IP bindings on

Dynamic IP Lockdown-enabled ports in this VLAN to be removed. The

port reverts back to switching traffic as usual.

Filtering IP and MAC Addresses Per-Port and Per-VLAN

This section contains an example that shows the following aspects of the

Dynamic IP Lockdown feature:

■ Internal Dynamic IP lockdown bindings dynamically applied on a per-port

basis from information in the DHCP Snooping lease database and stati-

cally configured IP-to-MAC address bindings

■ Packet filtering using source IP address, source MAC address, and source

VLAN as criteria

In this example, the following DHCP leases have been learned by DHCP

snooping on port 5. VLANs 2 and 5 are enabled for DHCP snooping.

The following example shows an IP-to-MAC address and VLAN binding that

have been statically configured in the lease database on port 5.

Table 1. Sample DHCP Snooping Entries

IP Address MAC Address VLAN ID

10.0.8.5 001122-334455 2

10.0.8.7 001122-334477 2

10.0.10.3 001122-334433 5

IP Address MAC Address VLAN ID

10.0.10.1 001122-110011 5
