HP 8719/20/22ES Specifications and Characteristics
Corrected System Performance (HP 8719/20ES)
Table 1-2 System Dynamic Range, All Device Connector Types
HP 8722ES, All Cal Kits, All Cables, 10 Hz IF BW
Description Specification Supplemental
Information
System Transmission Dynamic Range
HP 8722ES (Standard)
a
50 MHz to 840 MHz 67 dB
840 MHz to 8 GHz 93 dB
8 GHz to 20 GHz 91 dB
20 GHz to 40 GHz
80 dB
b
HP 8722ES (Option 007)
a
50 MHz to 840 MHz 72 dB
840 MHz to 8 GHz 98 dB
8 GHz to 20 GHz 96 dB
20 GHz to 40 GHz
85 dB
b
HP 8722ES (Option 012 with test set bypassed)
c
50 MHz to 500 MHz 115 dB, typ.
50 Hz to 8 GHz 115 dB, typ.
8 GHz to 20 GHz 113 dB, typ.
20 GHz to 40 GHz 108 dB, typ.
a. The System Transmission Dynamic Range is calculated as the difference
between the receiver noise floor and the lesser of either: the source maximum
output or the receiver maximum input. The receiver noise floor is specified as 3
standard deviations above the mean of the linear magnitude noise floor trace
over the specified frequency band.
b. 3 dB less for Option 085 or Option 012.
c. The System Transmission Dynamic Range is calculated as the difference
between the receiver noise floor and the lesser of either: the source maximum
output or the receiver maximum input. The receiver noise floor is specified as
the mean of the linear magnitude noise floor trace over the specified frequency
band.
