45
IMPORTANT:
The operating temperature is 0°C to 45°C (32°F to 113°F) for the JD121A and JD107A transceiver
modules, and 0°C to 50°C (32°F to 122°F) for all other transceiver modules.
NOTE:
• To guarantee the functionality of the transceiver module ports, use only HP transceiver modules.
• The transceiver modules available for this switch series are subject to change over time. For the most
up-to-date list of transceiver modules, consult your HP sales representative or technical support
engineer.
• For the transceiver module specifications, see
HP A-Series Switches Transceiver Modules User Guide .
For information about installing or removing a transceiver module, see
SFP/SFP+/XFP Transceiver
Modules Installation Guide
.
100 Mbps SFP transceiver modules
Product code Module Description
Central wavelength
(nm)
Fiber
diameter
(μm)
Maximum
transmission
distance
JD102B
HP X110 100M SFP LC FX
Transceiver
1310
50/125 2 km (1.24 miles)
62.5/125 2 km (1.24 miles)
JD120B
HP X110 100M SFP LC LX
Transceiver
1310 9/125
15 km (9.32
miles)
JD090A
HP X110 100M SFP LC
LH40 Transceiver
1310 9/125
40 km (24.86
miles)
JD091A
HP X110 100M SFP LC
LH80 Transceiver
1550 9/125
80 km (49.71
miles)
JD100A
HP X115 100M SFP LC BX
10-U Transceiver
TX: 1310
RX: 1550
9/125
15 km (9.32
miles)
JD101A
HP X115 100M SFP LC BX
10-D Transceiver
TX: 1550
RX: 1310
9/125
15 km (9.32
miles)
IMPORTANT:
You must use the transceiver modules coded D100A and JD101A in pairs.
1000 Mbps SFP transceiver modules
