HP A5500 HI Series User Manual

48
Figure 39 SFP+ cable
(1) Pull latch (2) Connector
10 Gbps XFP transceiver modules
Product
code
Module description
Central
wavelength
(nm)
Fiber
diameter
(μm)
Multimode
fiber modal
bandwidth
(MHz × km)
Max transmission
distance
JD117B
HP X130 10G XFP LC
SR Transceiver
850
50/125
2000 300 m (984.25 ft)
500 82 m(269.03 ft)
400 66 m(216.54 ft)
62.5/125
220 33 m (108.27 ft)
160 26 m (85.3 ft)
JD108B
HP X130 10G XFP LC
LR Transceiver
1310 9/125 N/A 10 km (6.21 miles)
JD121A
HP X135 10G XFP LC
ER Transceiver
1550 9/125 N/A 40 km (24.86 miles)
JD107A
HP X130 10G XFP LC
ZR Transceiver
1550 9/125 N/A 80 km (49.71 miles)
CX4 cables
Product code CX4 cable model Connector Max transmission distance
JD363B
HP X230 Local Connect 50cm
CX4 Cable
4X Infiniband 0.5 m (1.64 ft)
JD364B
HP X230 Local Connect 100cm
CX4 Cable
4X Infiniband 1 m (3.28 ft)
JD365A HP X230 CX4 to CX4 3m Cable 4X Infiniband 3 m (9.84 ft)
1
2
