Table 3-1 Computer major component descriptions and part numbers (continued)
Item Component Spare part number
Equipped with 4 GB of system memory and 32 GB of eMMC system storage M44236-001
System board I/O bracket (not illustrated) M45808-001
WLAN module bracket (not illustrated) M45807-001
(6) Heat sink (includes replacement thermal material) M44241-001
(7) Speaker (includes left and right speakers and cables) M44246-001
(8a) Battery shield L98587-001
(8b) Battery (2 cell, 47 Whr, 6.15 Ahr, Li) L75783-005
Battery tape (not illustrated) L14905-001
(9) Bottom cover
In jet black nish M44242-001
In nautical teal nish M44243-001
Display assembly subcomponents
To identify the display assembly subcomponents, use this illustration and table.
ENWW Display assembly subcomponents 13
