Service Reference Guide, dc5750 437963-001 7–7
Removal and Replacement Procedures— Small Form Factor (SFF) Chassis
7.6.1 Cable Connections
System board connectors are color-coded to make it easier to find the proper connection.
Cable
To Cable Designator
Power Supply Main power, P1 P1
Power Supply 1st SATA Hard drive P2
Power Supply CPU power P3
Power Supply 2nd SATA Hard drive P4
Power Supply SATA Optical drive P6
Power Supply Diskette drive P7
Power Supply SATA Optical drive P6
Cable To PCA Designator
Front LED/Power System board P5
Speaker System board P6, SPKR
Chassis fan System board P8, F CHASSIS FAN
Diskette drive System board P10, FLOPPY (Black)
Front audio System board P23, FRNT AUD, (Blue)
Front I/O USB System board P24, FRONT USB (Yellow)
Serial port B System board P52, COM B
1st SATA Hard drive System board P60, SATA0 (Dark Blue)
1st ODD or 2nd SATA Hard
drive if no ODD
System board P61, SATA1 (White)
ODD if 2nd SATA Hard drive
present
System board P62, SATA4 (Light blue)
To Next Page
