Removing an Optical Drive
CAUTION: All removable media should be taken out of a drive before removing the drive from the
computer.
To remove an optical drive:
1. Prepare the computer for disassembly (
Preparation for Disassembly on page 27).
2. Remove the computer access panel (
Computer Access Panel on page 31).
3. Remove the front bezel (
Front Bezel on page 32).
4. Disconnect the power cable (1) and data cable (2) from the rear of the optical drive.
5. Remove the screws that secure the drive to the drive cage (1), then slide the drive out of the front
of the chassis (2).
46 Chapter 6 Removal and Replacement Procedures Microtower (MT) Chassis
