How to order parts
The HP authorized repair center can purchase the power board from HP.
Power board
Description
HP spare part number
Manufacturer part number
Remark
PCBA, PI/BD, W/OSPK, LP24QJ-
A1V/E24d/HF
M84521-001
790PB1400A00H01
Common power
board of E24d
G4&E27d G4
Capacitors and connectors are available for purchase from the following EU distributors:
• Farnell: Farnell UK - Electronic Components Distributor
• RS Component: Capacitors | RS Components (rs-online.com)
• Digi-Key Component: Digi-Key Electronic United Kingdom
Capacitors by distributor
Component
description
Location
Component
distributor
Distributor part number
Capacitor 680 µF
10*12.5 10K
C816 and
C817
Farnell
16ZLH680MEFC10X12.5
Capacitor 680 µF
10*12.5 6K
16ZLS680MEFC10X12.5
Capacitor 680 µF
10*12.5 10K
RS
16ZLH680MEFC10X12.5
Connectors by manufacturer
Component description
Location
identifier
Component
distributor
Distributer part number
HDMI Port
CN201
Farnell
208658-1051
Display Port
CN301,
CN401
Farnell
47272-0001 (Notes: the rear cover and
chassis need to be modified to make the
connector opening larger)
Headphone
CN102
N/A
N/A (Please contact HP Service)
RJ45
CN901
Digi-Key
6116075-1 (Notes: the rear cover and
chassis need to be modified to make the
connector opening larger)
USB(VA)
P103, P104
Digi-Key
0484080003 (Notes: the rear cover and
chassis need to be modified to make the
connector opening larger)
USB(RA)
P701, P702
Farnell
48405-0003(Notes: the chassis and rear
cover need to be modified to make the
connector opening larger)
USB-C
P501, P1001
Farnell
DX07S024JJ2R1300
NOTE: The connector may need to be modified to meet functionality, regulatory and safety requirements if
it is not an exact match.
You can purchase cables from the HP part store at https://partsurfer.hp.com/Search.aspx.
