3. Remove the battery from the computer (3).
To insert the battery, reverse the removal procedures.
Solid-state drive
To remove the M.2 solid-state drive, use this procedure and illustration.
Table
5-3 Solid-state drive descriptions and part numbers
Description Spare part number
2 TB, PCIe-3 × 4, TLC L85358-002
1 TB, PCIe-3 × 4, TLC L85348-002
512 GB, PCIe-3 × 4, TLC L85360-002
Before removing the solid-state drive, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 29).
2. Remove the bottom cover (Bottom cover on page 29).
3. Disconnect the battery cable from the system board (see Battery on page 30).
Remove the solid-state drive:
32 Chapter 5 Removal and replacement procedures for authorized service provider parts
