Component Description
(3) Left Imagepad button The bottom left corner of the Imagepad functions like the left
button on an external mouse.
(4) Imagepad zone Moves the pointer and selects or activates items on the
screen.
(5) Right Imagepad button The bottom right corner of the Imagepad functions like the
right button on an external mouse.
Lights
Component Description
(1) Imagepad light
●
Amber: The Imagepad is off.
● Off: The Imagepad is on.
(2) Caps lock light
●
White: Caps lock is on.
● Off: Caps lock is off.
(3)
Power light
●
White: The computer is on.
● Blinking white: The computer is in the Sleep state.
● Off: The computer is off or in Hibernation.
(4)
Wireless light
●
White: An integrated wireless device, such as a
wireless local area network (WLAN) device, is
enabled.
●
Amber: All wireless devices are disabled.
(5)
Mute light
●
Amber: Speaker sound is off.
● Off: Speaker sound is on.
12 Chapter 2 Getting to know your computer
