Hard drive
NOTE: The hard drive spare part kit includes a hard drive bracket and hard drive connector. The
hard drive bracket and hard drive connector, as well as the hard drive bracket screws, are also
available in the Hard Drive Hardware Kit.
Description Spare part number
750 GB, 5400 rpm 619686–001
640 GB, 5400 rpm 603785–001
500 GB, 5400 rpm (for models 1.1 only) 634638-001
500 GB, 7200 rpm 610583-001
0 GB, 5400 rpm (for models 1.1 only) 622643-001
320 GB, 7200 rpm 603783-001
0 GB, 5400 rpm (for models 1.1 only) 622641-001
250 GB, 7200 rpm 635225-001
160 GB, 7200 rpm 615076-001
Hard drive hardware kit (not illustrated, includes connector, bracket, and screws) 605919-001
Before removing the hard drive:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn on
the computer, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first disconnecting the power cord from the AC
outlet and then disconnecting the AC adapter from the computer.
4. Remove the battery (see
Battery on page 41).
Remove the hard drive:
1. Position the computer with the front toward you.
2. Loosen the two Phillips PM2.5×6.0 captive screws (1) that secure the hard drive cover to the
computer.
42 Chapter 4 Removal and replacement procedures
